Underwater housing Ikelite for Canon 90D (DSLR)

Underwater housing Ikelite for Canon 90D (DSLR)

This housing features our robust Dry Lock (DL) port system. "Dry Lock" refers to the placement of the o-ring on the outside of the port mount. DL ports are the lightest on the market, yet robust and capable of standing up to rough surf. Most popular zoom lenses and select lens focus rings can be engaged using simple gearing that puts adjustment right at your fingertips. A large, soft-touch knob on the side of the housing makes fine tuned adjustments a breeze.

Ikelite port charts

Ikelite's detailed charts guide yout to correct port, wet optic, extention ring, as well as zoom or focus gear for your camera housing.

Pre-dive checks

There is no greater assurance than being able to see your camera and o-ring seal through the back of the housing. Our signature open-groove design suspends the rear o-ring in a natural position that is easier to maintain and more reliable than forcing the o-ring into a channel. Once the housing is closed you can see the o-ring form a solid, waterproof seal.
We recommend using a pump with gauge to pull a vacuum on the housing and check for leaks prior to entering the water.

Construction

Our specially formulated ABS-PC blend housing is highly durable yet significantly lighter than aluminum. The light color keeps your camera cooler when shooting in warm, sunny environments.

Lens support

Ikelite lens ports are the lightest on the market, yet robust and capable of standing up to rough surf.
We support a wide variety of lenses. Most popular zoom lenses and select focus rings can be engaged using simple gearing that puts adjustment right at your fingertips. Zoom and focus gears differ depending on which lens you are using.

Lens ports and zoom gears sold separately. Refer to the appropriate port chart for compatibility information.

Wi-Fi transfer

Use the camera's built-in Wi-Fi feature to download photos to another device without removing the camera from the housing. The Wi-Fi feature is only usable above water within close proximity to the connected device.

Compatibility

Unless otherwise noted, this housing does not accommodate the use of add-on grips, battery grips, eyepieces, LCD covers, or other accessories.
Differences in lens and control placement prevent other camera models from being used in or adapted to this housing. We are not aware of any other models which may be used in or adapted to this housing.

• 60m depth rating
• Compatible with DL system lens ports
• Controls are provided for all camera functions except: Diopter adjustment, Control wheel lock, LCD illuminating button, Flash button, Joystick up/down/left/right (Joystick can be depressed)
• 1/4-20 thread base mounts with 3.5" spacing
• Slightly positive buoyancy in fresh water
• Actual buoyancy varies depending on choice of lens and port
• Housing weight 2121 gram
• Tray with left handle 312 gram
• Size 229 x 178 x 165 mm
• Vacuum valve included (pump sold separately)
• Included Ikelite ICS-5 bulkhead connector with manual hotshoe for reliable electrical triggering of underwater strobes; Optional TTL accessories provides automatic exposure with compatible Ikelite DS strobes
• ABS-PC construction is fundamentally corrosion-resistant



In the Box

Housing
Rear O-ring #IK0132.59 (installed)
Front O-ring #IK0132.45 (installed)
Zoom Gear Retainer #IK75900 (installed)
Port Hole Cover #IK0200.92 (installed)
Waterproof Bulkhead Cap #IK9104.7 (installed)
Base with Left-Hand Quick Release Handle #IK4077.67 (installed)
Tool for Zoom Gear Retainer #IK0945.06
Hex Key
Silicone Lubricant 1cc Tube
