Underwater housing Ikelite Panasonic S5 II, S5 IIX

Ikelite's S5 II & S5 IIX housing give you control of Panasonic's powerful line of video-centric micro four-thirds cameras in a lightweight housing

In the box

Housing
Rear O-ring # 0132.59 (installed)
Front O-ring # 0132.45 (installed)
Zoom Gear Retainer # 75900 (installed)
Port Hole Cover # 0200.92 (installed)
Waterproof Bulkhead Cap # 9104.7 (installed)
Base with Left-Hand Quick Release Handle # 4077.67 (installed)
Tool for Zoom Gear Retainer # 0945.06
.050" Hex Key # 0945.11
Silicone Lubricant 1cc Tube

The housing

The Ikelite 200DL Underwater Housing is perfectly suited to making the most out of this powerful camera. Every element is optimized for lightweight strength, reliability, and field serviceability. This housing features our robust Dry Lock (DL) port system. "Dry Lock" refers to the placement of the o-ring on the outside of the port mount. DL ports are the lightest on the market, yet robust and capable of standing up to rough surf. Attachment is quick and secure.

A vacuum valve is installed standard on the side of the housing. The vacuum valve is designed to be low profile to avoid interference with controls. The optional Vacuum Pump with Gauge #IK47011 allows you to draw a vacuum on the housing to check for leaks prior to entering the water. The spare M16 threaded accessory port provides an attachment point for third party accessories including HDMI bulkheads. The standard viewfinder removes quickly and easily for the attachment of an optional Straight Magnified Viewfinder #IK6890.2 or 45° Magnified Viewfinder (Type 1) #IK6891.1

Specifications

60m depth rating
Compatible with DL system lens ports
1/4-20 thread base mounts with 3.5" spacing
Slightly positive buoyancy in fresh water
Actual buoyancy varies depending on choice of lens and port
Housing 2121 gram
Tray with left handle 312 gram
Vacuum valve included (pump sold separately)
Included Ikelite ICS-5 bulkhead connector with manual hotshoe for reliable electrical triggering of underwater strobes; Optional TTL accessories provides automatic exposure with compatible Ikelite DS strobes
Made in the USA; Individually inspected for fit and water pressure tested to depth
2 year limited warranty
