Underwater housing Ikelite for Sony FX3, FX30

Ikelite's Sony FX3 & FX30 underwater housing are designed from the ground up to provide full camera control and connection for external video lighting out of the box.

In the box

1. Housing
2. Rear O-ring # 0132.59 (installed)
3. Front O-ring # 0132.45 (installed)
4. Zoom Gear Retainer # 75900 (installed)
5. Port Hole Cover # 0200.92 (installed)
6. Waterproof Bulkhead Cap # 9104.7 (installed)
7. Base with Left-Hand Quick Release Handle # 4077.67 (installed)
8. Tool for Zoom Gear Retainer # 0945.06
9. .050" Hex Key # 0945.11
10. Silicone Lubricant 1cc Tube

The housing

The Sony FX3 & FX30 is a camera designed for photographers who love video and want great results without breaking the bank. The compact design makes it perfect for underwater photographers or shall I say videographers. It's part of Sony's Cinema Line, which means it's made for video but perfect for shooting both videos and photos.

DL ports are the lightest on the market, yet robust and capable of standing up to rough surf. Attachment is quick and secure. A system of extensions can accommodate a huge variety of lenses with ease. Most popular zoom lenses and select lens focus rings can be engaged using simple gearing that puts adjustment right at your fingertips. View the Sony port chart.

A vacuum valve is installed standard on the side of the housing. The vacuum valve is designed to be low profile to avoid interference with controls. The optional Vacuum Pump with Gauge #IK47011 allows you to draw a vacuum on the housing to check for leaks prior to entering the water. The spare M16 threaded accessory port provides an attachment point for third party accessories including HDMI bulkheads.

TTL Exposure/Strobes

This housings supports your choice of shooting with manual strobe exposure or adding a TTL converter depending on your application. The flash bulkhead is located on the top of the case to alleviate strain on the sync cord. You can enjoy the fastest and most accurate TTL exposure on the market by adding the DL2 DS Link Sony TTL Converter Ikelite ST1 Hotshoe Kit #IK46042 and a compatible Ikelite DS strobe.
SEA&SEA, INON, and Retra strobes with an electrical connection can be triggered in manual exposure modes using an electrical sync cord. Strobes without an electrical sync cord connection cannot be attached to this system unless slaved off of a hard-wired strobe.

The included SuperEye Viewfinder provides an enhanced view of the camera's electronic viewfinder when viewed through a dive mask. The viewfinder removes quickly and easily for the attachment of an optional Straight Magnified Viewfinder #IK6890.2 or 45° Magnified Viewfinder (Type 1) #IK6891.1

Specifications

• 60m depth rating
• Compatible with DL system lens ports
• 1/4-20 thread base mounts with 3.5" spacing
• Slightly positive buoyancy in fresh water
• Actual buoyancy varies depending on choice of lens and port
• Housing 2121 gram
• Tray with left handle  312 gram
• Vacuum valve included (pump sold separately)
• Included Ikelite ICS-5 bulkhead connector with manual hotshoe for reliable electrical triggering of underwater strobes; Optional TTL accessories provides automatic exposure with compatible Ikelite DS strobes
• Made in the USA; Individually inspected for fit and water pressure tested to depth
• 2 year limited warranty
