Home » Mirrorless & DSLR » Mirrorless UW housings » Underwater housing Ikelite for Canon R10 Deluxe (DLM)

Underwater housing Ikelite for Canon R10 Deluxe (DLM)

Ikelite R10 DLM deluxe housing package have advanced features. Delivered with Dual Tray with Dual Handles, Trigger Extensions, Vacuum System, and a set of spare O-Rings. Max depth: 60 m.
18 250 SEK
Part no: 69742-DLX

Description

Underwater housing Ikelite for Canon R10 Deluxe (DLM)

Configuration: Housing with Vacuum System & Handles

We've set up the Deluxe 200DLM Underwater Housing for Canon EOS R10 exactly the way we would use it with Dual Tray with Dual Handles, Trigger Extensions, Vacuum System, and a set of spare O-Rings.

Never before have we been so excited for a compact mirrorless camera. The combination of size, imaging quality, and value of the Canon EOS R10 system is unparalleled.

Port required


LENS PORT REQUIRED (Sold Separately)

A compatible lens port is required for waterproof operation (sold separately).
Choose the correct port components on the lens you will be shooting.
The port sizes are DL, DLM or the old FL

Ikelite port chart



Made in USA

This is a full featured and durable waterproof housing for Canon EOS R10 mirrorless digital cameras. Suitable for scuba, snorkel, surf, pool, and any application in or around the water. Our custom ABS-PC blend is lighter than aluminum yet strong enough for almost anything you want to throw at it.

The included Vacuum System allows you to check for leaks prior to entering the water.

The only system we want to shoot underwater right now

  • Controls are provided for everything except Diopter Adjustment Slider, Multi-Controller (can be pressed straight in), Depth-of-Field Preview Button, Focus Mode Switch
  • Strobe Connector Ikelite Bulkhead with Manual Hotshoe
  • Port Mount DLM (Dry Lock Micro)
  • Accessory Port 1/2-20 Thread
  • Depth Rating 200 feet (60 meters)
  • Weight 3 lb
  • Dimensions 7.5 x 5.9 x 6 in (191 x 150 x 152 mm)
  • Rear O-Ring 0110
  • Front O-Ring 0132.36



Pre-dive checks

There is no greater assurance than being able to see your camera and o-ring seal through the back of the housing. Our signature open-groove design suspends the rear o-ring in a natural position that is easier to maintain and more reliable than forcing the o-ring into a channel. Once the housing is closed you can see the o-ring form a solid, waterproof seal.
We recommend using a pump with gauge to pull a vacuum on the housing and check for leaks prior to entering the water.

Construction

Our specially formulated ABS-PC blend housing is highly durable yet significantly lighter than aluminum. The light color keeps your camera cooler when shooting in warm, sunny environments.

Lens support

Ikelite lens ports are the lightest on the market, yet robust and capable of standing up to rough surf.
We support a wide variety of lenses. Most popular zoom lenses and select focus rings can be engaged using simple gearing that puts adjustment right at your fingertips. Zoom and focus gears differ depending on which lens you are using.
Lens ports and zoom gears sold separately. Refer to the appropriate port chart for compatibility information.

Wi-Fi transfer

Use the camera's built-in Wi-Fi feature to download photos to another device without removing the camera from the housing. The Wi-Fi feature is only usable above water within close proximity to the connected device.

Compatibility

Unless otherwise noted, this housing does not accommodate the use of add-on grips, battery grips, eyepieces, LCD covers, or other accessories.
Differences in lens and control placement prevent other camera models from being used in or adapted to this housing. We are not aware of any other models which may be used in or adapted to this housing.

In the box

Housing
Rear O-Ring # 0110 (installed + spare)
Front O-Ring # 0132.36 (installed + spare)
Waterproof bulkhead cap # 9104.7 (installed)
(2) Trigger Extensions # 4077.95 (installed)
Vacuum valve (installed)
Vacuum pump with gauge # 47011
Tray with dual handles # 9523.64
Silicone lubricant 1cc tube

Manual



What's in the box
