Underwater housing Nauticam Nikon Z8

The Nauticam NA-Z8 professional aluminium underwater housing supports both Nikonís Z and F mount lenses. Bulkhead for HDMI 2.0, vacuum system and N120 port system for a large variety of ports to choose from.
51 550 SEK
Part no: 17229

Description

The NA-Z8 is the ultimate accessory for the powerful Nikon Z8 mirrorless camera.

What's in the box?

  1. NA-Z8 Housing with two handles and mount balls
  2. 90122 Spare main O-ring, O-ring remover and lubricant
  3. 2x Optical bulkhead caps
  4. Panasonic CR-2032 Battery (for moisture alarm)
  5. Set of Allen Keys
  6. Manual instruction card
  7. Padded housing bag and shoulder strap

The housing
The NA-Z8 uses the N120 Port System for Z-Mount full-frame lenses. When using F-mount lenses, the FTZ adapter is inside the housing which allows for the same port configuration as is found on an F-mount camera. Convenient lens release buttons on the housing for both F and Z mount makes lens changes a snap regardless of platform without having to remove the camera from the housing; only when installing or removing the FTZ adapter.

Electronic viewfinders are constantly achieving higher resolution and better dynamic range and the Z8 features a 3690k-dot OLED 0.5" viewfinder. Pair the Z8's viewfinder with Nauticam's full frame enhanced viewfinders for unrestricted viewing of the entire EVF in either a straight or angled configuration. The added working distance from the back of the housing makes for a more comfortable and natural position underwater. Edge to edge visibility and a dioptric adjustment make for easier composition and tack-sharp focus.

As a true hybrid shooting platform the NA-Z8 is just as comfortable being outfitted to capture video as stills. External monitors and recorders can easily be connected via the large M24 bulkhead which supports both HDMI 1.4 and HDMI 2.0 connections.

Optics

The WACP-1 Wide Angle Conversion Lens works flawlessly with the Nikkor Z 28-75mm f/2.8 lens to deliver an impressive 130º field-of-view at 28mm and 83º at 48mm. A ~0" minimum focus distance and small front element makes composition and lighting even easier. Those looking for a more compact system can use the new WACP-C with the Sony SEL2870 28-70mm f3.5-5.6 OSS lens plus the Megadap ETZ 21 adapter which delivers full zoom through and a 130º to 59º field-of-view. Want greater than 1:1 magnification with unmatched sharpness? The SMC-1 and SMC-2 provide 2.2x and 3.6x magnification respectively with the Nikkor Z MC 105mm f/2.8 VR S Macro lens and can be easily mounted with the Nauticam flips system allowing for fast deployment as well as secure and accurate placement of the optics.

NA-Z8 embodies Nauticam's mission control design philosophy placing essential controls within easy reach of the reinforced molded handles.

Specifications

  • Depth Rating 100m
  • Dimensions 356mm x 204mm x 163mm
  • Weight in Air 3.4kg
  • Buoyancy in Water Negative 0.05kg (includes camera & battery)
  • Port Mount N120
  • Front Accessory Ports 1x M24 and 1xM16, 1x M10 and 4x 1/4-20UNC threaded hole.
  • Rear Accessory Ports 1x M16
