Underwater housing Nauticam for ARRI Alexa 35

Designed with easy use and reability for owner and film crews in mind. The Alexa 35 housing package include a heavy duty transport case.

In The Box

1. #16139 Digital Cinema System for ARRI ALEXA 35 Camera
2. 3 Lens Control Assemblies with stackable drive shafts and 15mm rods
3. Vacuum Check & Leak Detection System, Dual Activation Vacuum Valve
4. Quick release and adjustable top handle, left handle and right handle
5. Housing Skids
6. Trim Weight Kit
7. 1x Travel Hard Case
8. Tool Kit & O-ring Kit

The housing

The Nauticam system is very easy to set up. Armed with only a coin and an allen wrench, the entire support and lens control system is constructed on the camera base plate outside of the housing. This means the rig can be built on a table, in good light, with plenty of working space. Once the camera is assembled on its tray, the entire system slides into the housing, and locks securely in place. Trim weights are included and can be moved independently along the length of the hosuing skids and additional mounting points are featured on the housing itself to trim the housing to the shooter's exact needs. Vacuum system and leak sensor are included in the package.

Lens control

The ALEXA 35 housing features an adjustable gear tower to control Focus, Iris and Zoom all from the knurled knobs on the exterior of the housing. This "diver controlled" setup completely satisfies the needs of a single operator. For more production oriented shoots which require remote operation and control, the newly designed Nauticam ALEXA 35 housing features two upper and two lower 15mm rods allowing the use cforce Plus and cforce mini motors paired with the ARRI Hi-5 Hand Unit. Only the upper 15mm rods will support the larger cforce Plus motors. Unlike previous generation housings, the motors will now drive the lens itself rather than through the adjustable gear tower. With the standard housing, two motors can be mounted for short primes.
The housing also ships with one 3/4″ Hydroflex style bulkhead allowing the power, remote control, and remote monitor umbilical from other Hydroflex rental systems to be used on Alexa Mini. A tremendous range of lenses is supported, from very small Zeiss Standard Speeds, to very large cinema styled zooms. Our port system has been tested with Arri UWZ 9.5-18, the most sophisticated wide angle lens ever produced, with excellent results.

Glas dome port

Our exclusive 250mm optically coated glass dome port is supplied with every system, and we believe it is the best optic available for cinema lenses. The 250mm dome port diameter – 10 inches – is a key for good wide angle imaging performance with many cinema lenses underwater. Smaller domes can work well with close focusing SLR lenses, but many cinema lenses have a longer minimum focus distance in the .35-.40m (14-16″) range. Using Arri Master Prime T1.4/14mm, with its .4m MFD as an example, the 250mm dome provides clearly superior results, with much less corner softness than smaller domes. The glass dome is rugged, and extremely resistant to scratching.

Batteries

The housing ships with an V-Mount battery plate and LEMO connector for the ALEXA 35 camera. Ample space is available for a range of battery pack sizes to be used in the housing, providing long operation times. Surface suppled power is also an option for for tethered all day shooting.

External monitor/recorder

The SmallHD 503 Ultrabright or the Atomos Ninja V monitor can be mounted in the Nauticam NA-503-S or Nauticam Atomos Ninja V-S housings and be connected via SDI bulkheads and cables allowing greater flexibility when positioning the monitor on the Nauticam Alexa 35 housing.

Specifications

• Depth Rating Housing: 80m
• Depth rating 250mm Optical Glass Dome: 45m
• Weight in air (housing only) 11.6kg
• Weight in air (incl. internal and external accessories) 17.5kg
• Buoyancy in water (incl. camera, lens, bebob B290 battery and 250mm dome) 0.8kg
• Dimensions (W x H x D) 310mm x 246mm x 400mm
• Port System N200
